Facet 476459 Silver Top Competition Cylindrical Fuel Pump - STC505
Facet 476459 Silver Top Competition Cylindrical Fuel Pump - STC505
An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.
Specification:- Fast Road
Pump:- 476459E
Voltage:- 12v
Earth:- Neg
Pressure (Psi):- 6.0-7.0
Flow:- US Gallons/Hr 35
Dry Prime Height in Mtrs:- 0.6
Thread Size:- 1/8th nptf
Operating Temperature:- -40º to +180° F (all Models)
Average Run Time or MTBF:- 6000 hrs
Legal Requirements:- Certified & Complies With EEC 95/54 Requirements
Length:-140mm
Diameter:- 54mm
Weight:-0.7kg
Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight
Applications:- Motorsport, Marine
Cross Reference:-
| HP3190 | |
| 30-00106 | |
| 170351C1 | |
| 170352C1 | |
| AR65058 |
| Product Code | STC505 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Colour | Silver | ||||||||||
| Voltage | 12v DC | ||||||||||
| Manufacturer | Facet | ||||||||||
| Description | Facet 476459 Silver Top Competition Cylindrical Fuel Pump - STC505 An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible. Specification:- Fast Road Average Run Time or MTBF:- 6000 hrs Legal Requirements:- Certified & Complies With EEC 95/54 Requirements Length:-140mm Diameter:- 54mm Weight:-0.7kg Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight Applications:- Motorsport, Marine Cross Reference:-
|
