Facet 480534 Blue Top Cylindrical Fuel Pump - BTP001
Facet 480534 Blue Top Cylindrical Fuel Pump - BTP001
An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.
Specification:- Blue Top (Diesel / Petrol)
Earth:- Neg
Pressure (Psi):- 6.0-8.0
Flow:- US Gallons/Hr 45
Dry Prime Height in Mtrs:- 0.6
Thread Size:- 1/4 npt
Filter (Micron):- 400
Operating Temperature:- -40º to +180° F (all Models)
Average Run Time or MTBF:- 6000 hrs
Legal Requirements:- Certified & Complies With EEC 95/54 Requirements
Length:-140mm
Diameter:- 54mm
Weight:-0.7kg
Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight
| Product Code | BTP001 |
|---|---|
| Fuel | Petrol up to E10, Petrol + E85, Diesel, Petrol up to E5 |
| Voltage | 12v DC |
| Manufacturer | Facet |
| Description | Facet 480534 Blue Top Cylindrical Fuel Pump - BTP001 An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible. Specification:- Blue Top (Diesel / Petrol) Filter (Micron):- 400 Average Run Time or MTBF:- 6000 hrs Legal Requirements:- Certified & Complies With EEC 95/54 Requirements Length:-140mm Diameter:- 54mm Weight:-0.7kg Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight |
