Facet Solid State Fuel Pump Clamshell Kit FEP12SV
These solid-state technology electronic fuel pumps provide outputs up to 132.5 liters/hour and .68 bar. Facet/Purolator Cube Fuel Pumps are self-priming with a dry lift capacity of 120 inches. Two universal models provide complete coverage for all low and high-pressure carburetor applications for cars, vans, RV’s, and light trucks, in addition to many diesel applications. All models of the Facet/Purolator Cube Fuel Pumps are compatible with gasoline, diesel, biodiesel, blended alcohol fuels, and fuel additives.
Specification:- Fast Road
Pump:- 40106
Voltage:- 12v
Earth:- Neg
Pressure (Psi):- 4.5-7.0
Flow:- US Gallons/Hr 32
Dry Prime Height in Mtrs:- 0.3
Thread Size:- 1/8th nptf
Positive Shut-Off Valve:- No
Check Valve:- No
Operating Temperature:- -31º F to 55° F (all Models)
Legal Requirements:- Certified & Complies With EEC 95/54 Requirements
Length:- 75mm
Height:- 60mm
Weight:-0.5kg
Please Note:- The product in not suitable for use in the aircraft industry
| Product Code | FEP12SV |
|---|---|
| Voltage | 12v DC |
| Manufacturer | Facet |
| Description | These solid-state technology electronic fuel pumps provide outputs up to 132.5 liters/hour and .68 bar. Facet/Purolator Cube Fuel Pumps are self-priming with a dry lift capacity of 120 inches. Two universal models provide complete coverage for all low and high-pressure carburetor applications for cars, vans, RV’s, and light trucks, in addition to many diesel applications. All models of the Facet/Purolator Cube Fuel Pumps are compatible with gasoline, diesel, biodiesel, blended alcohol fuels, and fuel additives. Positive Shut-Off Valve:- No Check Valve:- No Operating Temperature:- -31º F to 55° F (all Models)
Legal Requirements:- Certified & Complies With EEC 95/54 Requirements Length:- 75mm Height:- 60mm Weight:-0.5kg Please Note:- The product in not suitable for use in the aircraft industry |
